Facilities
Specification of facilities for testing performance of hydro turbine
![성능시험 설비사양](/kiwe/web/eng/images/supp/img_valve03.jpg)
![성능시험 설비사양](/kiwe/web/eng/images/supp/m_img_valve03.jpg)
- Total ground area : 300 ㎡
- Fall head : 40 m
- Rate of flow : 1.0 ㎥/s
- Rotation speed : 2,500 rpm
- tems : Efficiency, nonrestraint, cavitation, axial trust, etc.
- Testable scope : : Performance of model hydro turbine of actual hydraulic turbine generator of 100MW max.
- Testable turbine : : Performance of every scaled hydro turbine model
- Bulb hydro turbine
![Bulb hydro turbine](/kiwe/web/eng/images/supp/img_valve04.jpg)
- Francis turbine
![Francis turbine](/kiwe/web/eng/images/supp/img_valve05.jpg)
- Kaplan turbine
![Kaplan turbine](/kiwe/web/eng/images/supp/img_valve06.jpg)
- Diagonal flow hydro turbine
![Diagonal flow hydro turbine](/kiwe/web/eng/images/supp/img_valve07.jpg)
- Pelton wheel
![Pelton wheel](/kiwe/web/eng/images/supp/img_valve08.jpg)
Specification of facility for valve & fluid flow test
![Specification of facility for valve & fluid flow test](/kiwe/web/eng/images/supp/w_img_valve11.jpg)
![밸브 및 유체츄동 성능시험](/kiwe/web/eng/images/supp/img_valve11.jpg)
- Total ground area : 2,600 ㎡
- Testing capacity : 3~2,700 ㎥/h
- Maximum diameter : 800 mm
- Items : Capacity coefficient, pressure recovery factor, cavitation, water hammer, etc.
![Block diagram of valve performance test (ISA 75.02 code)](/kiwe/web/eng/images/supp/img_valve1102.jpg)
<Block diagram of valve performance test (ISA 75.02 code)>
- Source
- Temperature Sensor
- Upstream Throtting value
- Flow
- Flow Sensor
- Test Specimen
- Test Section
- Pressure Taps
- Downstream Throttlin valve
